Solar plant design course, Solar design online training course, Institute for solar design, Delhi, India

Solar Power Plant Design Online training Course

Advance Electricald Design & Engineering Institutes's Solar Designing Online training courses are developed using the latest technologies and incorporate rich graphics, interactive features, and Live Class rooms. Designed to complement each other, the online solar courses can be followed by one of the hands-on workshops to put theory into practice. In addition to online curriculum, students will receive support from professional industry instructors. Online course instructors will be available to answer all your questions and guide you through the material all along the way, with email, live chat, office hours.A course glossary, extensive Internet resources and case studies are included in the online classroom. To help address the growing need for qualified solar Designers and provide quality education to both enthusiasts and professionals the following courses are available at launch:



Who should attend:
solar design online training course Anybody who wants to gain valuable hands-on experience, especially electrical and mechanical engineers; electrical and general contractors, electrical designers, solar companies and solar industry professionals who want to further their knowledge of solar design.

Prerequisites: Participants should have a basic understanding of solar PV or basic solar design, PV installation or related experience. Participants should also have knowledge of Electrical.

What time:

  • Weekend Batch : Saturday and Sunday
  • Time : 2 Hours/per day (Flexible timming as required)

How much:  The fee is $750 per person.  Fee includes
course materials with Softwares .

How to Register: We offer the following options to register for this class. Class size is limited, so we recommend that you register early to guarantee a seat.

1. Online - click on the Enroll Now button below and register using a credit card or check card. You will be redirected to our online payment page for a safe, secure transaction. You will receive an email confirmation when the transaction is complete.
2. By phone – simply call us at (+91) 8467024957,7531923094 and we'll process your registration over the phone.
3. By whatApp on (+91) 8467024957,7531923094
4. Skype Id : aedei01


Upcoming Courses
Start Date End Date Location Fee ID Status
19/08/17
19/10/17
New Delhi
$750
900
Enroll Now!





Syllabus of Solar design online course
solar design training syllabus

Chapter 1 - Solar Radiation

  1. Irradiation and PeakSun Hours
  2. Solar Radiation Data
  3. Sunpath Diagram
  4. Defining the Position of the Sun
  5. Solar Altitude
  6. Geometric Effects
  7. Tilting Solar Modules
  8. Magnetic North & True North

Chapter - 2 Connection of PV Module(Series and Parallel Circuit)

  1. SeriesCircuits
  2. Parallel Circuits
  3. Combining Series & Parallel Circuits
  4. Understanding Cell Connection
  5. Array

Chapter- 3 PV Cells Selection and Sizing

  1. Introduction
  2. Characteristics of a Solar Cell
  3. Power Characteristics of a Solar Cell
  4. Fill factor and Equivalent Solar cell Circuit
  5. STC and NOCT
  6. Factors Which Affect the Performance of Solar Cells
  7. Types of Solar Cells
  8. Manufacture of Silicon Solar Cells
  9. Commercial Modules v ElectricaI Protection
  10. Module Realibility

Chapter 4 - Inverters Selection and Sizing(Grid Connection and Off Grid)

  1. Purpose of inverters
  2. Grid-Connected Inverters vs. Stand-Alone Inverters
  3. Types of Grid-Connected inverters: Introduction
  4. Isolated Inverters
  5. Types of Inverters - PV to Inverter Interface
  6. Inverter Protection Systems
  7. Power Quality
  8. Monitoring
  9. Inverter Products For Use In India

Chapter 5 - Module Mounting Systems

  1. Introduction
  2. Calculating the Wind Loading of the Solar Array
  3. Roof Mounted Systems
  4. Systems
  5. PV Array Row Spacing
  6. Ground Mounted Systems

Chapter 6 -Solar Power Plant Balance of System

  1. Introduction
  2. Cabling
  3. Array String Protection and Disconnect Switches
  4. Lightning Protection
  5. Array Junction Box
  6. PVMain Disconnection Devices
  7. Metering
  8. System Monitoring: Local and/or Web Based Display

Chapter 7 - Energy Efficiency and Calculation

  1. Introduction
  2. Energy Efficiency Measures
  3. Overview of Passive Solar Design Principles

Chapter 8 -Solar power Plant Site Survey & Assessment

  1. Introduction
  2. Undertaking a Site Assessment
  3. Choosing a PV Module
  4. Choosing an Inverter
  5. Choosing a Mounting System Type
  6. Determining the Maximum Number of Modules That Can Fit on a Roof

Chapter 9- Matching Array and Inverter Sizing

  1. Matching The PV Array ToThe Voltage Specifications of An Inverter
  2. Matching the PVArray to the Inverter's Current Rating
  3. Matching the PVArray to the Inverter's Power Rating
  4. Summary of Calculations for Matching Array and Inverter

Chapter 10 -Solar Power Plant System Protection

  1. Determining the Protection Equipment and Switching
  2. PV Array Maximum Voltage
  3. Circuit Protection: Over-Current
  4. Disconnection Devices
  5. System Earthing
  6. Connecting the System to the Grid

Chapter 11 - System Losses of Solar Power Plant

  1. Determining the Size of the DC and AC Cables
  2. Losses in a Grid-Connected PV System

Chapter 12 - Solar Power System Yield Performance(Energy Guarantee)

  1. What Determines the Energy of a System
  2. Calculating the Energy Yield for a PV Grid-Connected System
  3. Specific Yield
  4. Performance Ratio
  5. CUF Calculation

Chapter 13 - Plant Installation And Commissioning

  1. IEC Standards
  2. Equipment Selection-Warranties
  3. Installation Preparation
  4. Equipment Installation
  5. Monitoring Equipment
  6. Commissioning
  7. System Documentation
  8. System Installation & Pre-Commissioning Checklist
  9. Commissioning Test Sheets

Chapter 14 - Maintenance And Troubleshooting

  1. System Maintenance
  2. Troubleshooting

Chapter 15 -Megawatt Solar Plant System

  1. Introduction
  2. Preliminary Planning
  3. Designing a Large PV Grid Connect System
  4. What Array/Inverter Configuration Should Be Selected?
  5. Monitoring

Chapter 16 - Costing and Tendering Of Solar Power Plant

  1. Introduction
  2. Simple Payback
  3. Life Cycle Costing
  4. Determining Costs Associated with the Whole PV System
  5. Valuing a PV System

Chapter 17 - Smart Grid/Net Metering

  1. Smart Grid
  2. Smart Meters
  3. PVsyst, meteonorm, Google sketchup
  • Ref. Std. IEC IEC 60068-2 (1,2,14,30),IEC
    61683,IEC 60227,IEC 60502 IEC 60947 part I,II, III ,IEC 61215
